Kramer 4K60 4:4:4 4x1 HDMI Automatic Switcher with Audio De-Embedding and IP Control (Black)
Kramer 4K60 4:4:4 4x1 HDMI Automatic Switcher with Audio De-Embedding and IP Control (Black)
The SWT3−41−H is an intelligent 4x1 HDMI automatic switcher designed for seamless 4K60 4:4:4 video signal management. With a plug-and-play experience, it automatically switches inputs based on priority or last-connected active video signal detection, while also offering easy IP-driven remote control.
Auto Switching Made Easy:
Automatically selects and plays the active source on your display according to user-configured preferences. Manual switching via panel buttons temporarily overrides auto-switching.
Advanced HDMI Signal Support:
Fully HDCP 2.2 compliant, supporting deep color, lip sync, uncompressed audio, Dolby TrueHD, DTS-HD, 2K, 4K, and 3D content in line with HDMI 2.0 specifications.
Intelligent EDID Processing:
Ensures seamless plug-and-play operation with intelligent EDID handling, processing, locking, and pass-through for all HDMI sources and displays.
Multi-Channel Audio Switching:
Supports up to 32 channels of digital stereo uncompressed audio for studio-grade surround sound experiences.
Audio De-embedding:
Extracts HDMI digital audio, converting it to analog stereo output for professional audio systems, while simultaneously playing audio on connected display speakers.
Smart Display Control:
Automatically or manually powers CEC-enabled or serially-controlled displays on source connection/disconnection, with user-defined shutdown delays.
Flexible Control Options:
Operate the switcher via remote IP, browser interface, local panel buttons, or contact-closure triggers, offering fully configurable signal routing and user port selection.
Built-in Control Gateway:
Manage HDMI and sensor devices directly via RS–232 or I/O, eliminating the need for an external control gateway and simplifying system integration.
Secured IT Operation:
Supports 802.1x authentication for secure IT-grade LAN connectivity.
Comprehensive Management:
Local and remote control options, including panel buttons, contact closures, embedded web pages, and RS–232 API commands for flexible system management.
Easy Installation:
Compact, fanless enclosure supports PoE via LAN, tabletop placement, or dual-side-by-side 1U rack mounting with optional adapter.
More Images
Kramer 4K60 4:4:4 4x1 HDMI Automatic Switcher with Audio De-Embedding and IP Control (Black)
The SWT3−41−H is an intelligent 4x1 HDMI automatic switcher designed for seamless 4K60 4:4:4 video signal management. With a plug-and-play experience, it automatically switches inputs based on priority or last-connected active video signal detection, while also offering easy IP-driven remote control.
Auto Switching Made Easy:
Automatically selects and plays the active source on your display according to user-configured preferences. Manual switching via panel buttons temporarily overrides auto-switching.
Advanced HDMI Signal Support:
Fully HDCP 2.2 compliant, supporting deep color, lip sync, uncompressed audio, Dolby TrueHD, DTS-HD, 2K, 4K, and 3D content in line with HDMI 2.0 specifications.
Intelligent EDID Processing:
Ensures seamless plug-and-play operation with intelligent EDID handling, processing, locking, and pass-through for all HDMI sources and displays.
Multi-Channel Audio Switching:
Supports up to 32 channels of digital stereo uncompressed audio for studio-grade surround sound experiences.
Audio De-embedding:
Extracts HDMI digital audio, converting it to analog stereo output for professional audio systems, while simultaneously playing audio on connected display speakers.
Smart Display Control:
Automatically or manually powers CEC-enabled or serially-controlled displays on source connection/disconnection, with user-defined shutdown delays.
Flexible Control Options:
Operate the switcher via remote IP, browser interface, local panel buttons, or contact-closure triggers, offering fully configurable signal routing and user port selection.
Built-in Control Gateway:
Manage HDMI and sensor devices directly via RS–232 or I/O, eliminating the need for an external control gateway and simplifying system integration.
Secured IT Operation:
Supports 802.1x authentication for secure IT-grade LAN connectivity.
Comprehensive Management:
Local and remote control options, including panel buttons, contact closures, embedded web pages, and RS–232 API commands for flexible system management.
Easy Installation:
Compact, fanless enclosure supports PoE via LAN, tabletop placement, or dual-side-by-side 1U rack mounting with optional adapter.
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
The SWT3−41−H is an intelligent 4x1 HDMI automatic switcher designed for seamless 4K60 4:4:4 video signal management. With a plug-and-play experience, it automatically switches inputs based on priority or last-connected active video signal detection, while also offering easy IP-driven remote control.
Auto Switching Made Easy:
Automatically selects and plays the active source on your display according to user-configured preferences. Manual switching via panel buttons temporarily overrides auto-switching.
Advanced HDMI Signal Support:
Fully HDCP 2.2 compliant, supporting deep color, lip sync, uncompressed audio, Dolby TrueHD, DTS-HD, 2K, 4K, and 3D content in line with HDMI 2.0 specifications.
Intelligent EDID Processing:
Ensures seamless plug-and-play operation with intelligent EDID handling, processing, locking, and pass-through for all HDMI sources and displays.
Multi-Channel Audio Switching:
Supports up to 32 channels of digital stereo uncompressed audio for studio-grade surround sound experiences.
Audio De-embedding:
Extracts HDMI digital audio, converting it to analog stereo output for professional audio systems, while simultaneously playing audio on connected display speakers.
Smart Display Control:
Automatically or manually powers CEC-enabled or serially-controlled displays on source connection/disconnection, with user-defined shutdown delays.
Flexible Control Options:
Operate the switcher via remote IP, browser interface, local panel buttons, or contact-closure triggers, offering fully configurable signal routing and user port selection.
Built-in Control Gateway:
Manage HDMI and sensor devices directly via RS–232 or I/O, eliminating the need for an external control gateway and simplifying system integration.
Secured IT Operation:
Supports 802.1x authentication for secure IT-grade LAN connectivity.
Comprehensive Management:
Local and remote control options, including panel buttons, contact closures, embedded web pages, and RS–232 API commands for flexible system management.
Easy Installation:
Compact, fanless enclosure supports PoE via LAN, tabletop placement, or dual-side-by-side 1U rack mounting with optional adapter.
