Marshall Electronics CV612-TBI Compact PTZ Camera with AI Auto-Framing (Black)
Marshall Electronics CV612-TBI Compact PTZ Camera with AI Auto-Framing and 12x Optical Zoom (Black)
AI Auto Track Technology
The CV612 models can automatically track, follow, and frame presenters using AI facial learning for accurate and smooth self-adjusting maneuvers. Tracking features include Presenter real-time tracking and Zone regional tracking. Presenter mode follows a single person and ignores others. Regional mode follows a person from one established shot to another.
Live Streaming Made Simple
The camera can stream HEVC/H.264 directly via RTSP/RTMP/SRT while simultaneously outputting video via SDI, HDMI, making it an ideal solution to stream live to YouTube, Livestream, Facebook (Meta), Twitch, etc. High-quality USB-C is also available. When USB and SDI are set to the same format/frame rate, all four video output types are available simultaneously.
Flexibility Workflow
CV612 camera is equally at home in houses of worship, classrooms, reality shows, podcasting channels, and corporate boardrooms. Its compact size allows it to fit on a desktop, on a shelf, or concealed by set decorations in a reality shoot. It operates equally well on a surface or mounted upside down from an overhead location.
High Compatibility
Multiple output types, multiple control methods, and P0E+ power make life easy for system designers. Nearly all common control methods are supported, including Visca and Pelco (RS232), Visca-over-IP, ONVIF, USB UVC, Web Browser setup and control, plus a hand-held IR Remote. It's a perfect match for Marshall’s VS-PTC-300 PTZ control panel as well as many 3rd party products.
Features:
- Accurate auto-track, follow, and frame subjects using AI facial learning technology
- 1/2.8in high-quality HD CMOS sensor with 2.07 megapixel-inch
- Format Resolutions 1920x1080, 1280x720, 640x480
- Video outputs include: 3GSDI, HDMI, USB3.0 and IP
- 12x optical zoom (4.1~49.2mm)
- Supports real-time tracking and regional tracking up to 8m
- Dante Ready AV-H supports up to 1080p and 2 audio channels (Requires end user activation in Dante Controller)
- Horizontal Angle of View 6.6 degrees- 70.3 degrees
- Pan rotation of +/- 170degree, Tilt rotation of -90 degrees-+90 degrees
More Images
Marshall Electronics CV612-TBI Compact PTZ Camera with AI Auto-Framing (Black)
Marshall Electronics CV612-TBI Compact PTZ Camera with AI Auto-Framing and 12x Optical Zoom (Black)
AI Auto Track Technology
The CV612 models can automatically track, follow, and frame presenters using AI facial learning for accurate and smooth self-adjusting maneuvers. Tracking features include Presenter real-time tracking and Zone regional tracking. Presenter mode follows a single person and ignores others. Regional mode follows a person from one established shot to another.
Live Streaming Made Simple
The camera can stream HEVC/H.264 directly via RTSP/RTMP/SRT while simultaneously outputting video via SDI, HDMI, making it an ideal solution to stream live to YouTube, Livestream, Facebook (Meta), Twitch, etc. High-quality USB-C is also available. When USB and SDI are set to the same format/frame rate, all four video output types are available simultaneously.
Flexibility Workflow
CV612 camera is equally at home in houses of worship, classrooms, reality shows, podcasting channels, and corporate boardrooms. Its compact size allows it to fit on a desktop, on a shelf, or concealed by set decorations in a reality shoot. It operates equally well on a surface or mounted upside down from an overhead location.
High Compatibility
Multiple output types, multiple control methods, and P0E+ power make life easy for system designers. Nearly all common control methods are supported, including Visca and Pelco (RS232), Visca-over-IP, ONVIF, USB UVC, Web Browser setup and control, plus a hand-held IR Remote. It's a perfect match for Marshall’s VS-PTC-300 PTZ control panel as well as many 3rd party products.
Features:
- Accurate auto-track, follow, and frame subjects using AI facial learning technology
- 1/2.8in high-quality HD CMOS sensor with 2.07 megapixel-inch
- Format Resolutions 1920x1080, 1280x720, 640x480
- Video outputs include: 3GSDI, HDMI, USB3.0 and IP
- 12x optical zoom (4.1~49.2mm)
- Supports real-time tracking and regional tracking up to 8m
- Dante Ready AV-H supports up to 1080p and 2 audio channels (Requires end user activation in Dante Controller)
- Horizontal Angle of View 6.6 degrees- 70.3 degrees
- Pan rotation of +/- 170degree, Tilt rotation of -90 degrees-+90 degrees
