Kramer 4K HDMI Distribution Amplifier with HDCP2.2 and HDMI2.0 support

VM−2H2 is a 1:2 distribution amplifier for up to 4K HDR, HDMI signals that comply with HDCP 2.2 content protection standard. The unit takes one HDMI input, equalizes and reclocks the signal, and distributes it to two identical outputs.

Max. Data Rate

17.82Gbps (5.94Gbps per graphic channel).

Max. Resolution

4K@60Hz (4:4:4).

HDMI Signal Transmission

HDR, HDCP 2.2 compliant signal, supporting deep color, x.v.Color, lip sync, 7.1 PCM, Dolby TrueHD, DTS–HD, CEC (OUT 1 only), 2K, 4K, and 3D as specified in HDMI 2.0.

Intelligent EDID Handling

Use connected display EDID or default EDID, with EDID lock and RGB–force options, to ensure proper operation of HDMI source and display systems.

Kramer Equalization & re-Klocking Technology

Rebuilds the digital signal to travel longer distances.

Force RGB

When the display lacks YCbCr capabilities, the user can force native delivery of the RGB color format in HDMI content to improve picture quality.

Selectable HDCP Authorization

Allows the user to control the appearance of an HDCP or non–HDCP input to the source to permit delivery of protection–free content, such as personal clips and charts, without HDCP encryption. HDCP-protected content is not passed in non–HDCP mode.

Field Maintenance

RS–232 connection for simple field firmware upgrade, status indicators for HDMI input and output connected signals, and a power indicator, for ease of maintenance and troubleshooting.

Easy Installation

Compact Mega TOOLS fan–less enclosure for over–ceiling mounting, or side–by–side rack mounting.
